| Parameter | Unit | Specification (Single mode) |
|---|---|---|
| Connector type | - | LC Duplex |
| Type | - | UPC |
| Insertion Loss (IL) | dB | ≤0.2 |
| Return Loss (RL) | dB | ≥45dB |
| Exchangeability | dB | IL ≤0.2 |
| Repeatability (500 remates) | dB | IL ≤0.2 |
| Sleeve material | - | Zirconia Ceramic |
| Housing Material | - | Plastic |
| Operating Temperature | °C | -20°C ~ +70°C |
| Storage Temperature | °C | -40°C ~ +70°C |
| Standard | - | TIA/EIA-604 |
Fully compatible with standard LC duplex connectors.
Zirconia alignment sleeve supports both Multimode and Single Mode applications.
Durable metal side spring ensures tight fit; integrated mounting clip allows for easy snap-in installation.
Designed for reduced fiber optic signal loss and high durability.
Lightweight and durable plastic body equipped with standard plug-style dust caps.
100% tested before shipment. OEM service is acceptable.
Fiber optic adapters (also called couplers) are specifically designed to connect two fiber optic cables together, ensuring proper and precise alignment of the connector tips (ferrules).
The single mode LC duplex adapter has an Insertion Loss (IL) of ≤0.2 dB and a Return Loss (RL) of ≥45dB, which helps in reducing fiber optic signal loss.
Yes, these LC Fiber Optic Duplex Adapters are designed to fit standard Simplex SC adapter cutouts for patch panels, cassettes, adapter plates, and wall-mounts.
These adapters feature a high-quality Zirconia Ceramic alignment sleeve, which is highly compatible with both Multimode and Single Mode applications.
They comply with the TIA/EIA-604 standard, making them compatible with SFF (small form factor) requirements and standard LC duplex connectors.
The adapters can operate in temperatures ranging from -20°C to +70°C, and can be stored in temperatures from -40°C to +70°C.
