| Parameter | Specification |
|---|---|
| Switching capacity (control board) / System Layer 2 packet forwarding rate | MCUD/MCUD 1: 128 Gbit/s (active/standby mode), 256 Gbit/s (load-sharing mode) |
| Switching/Forwarding delay | The 100 Mbit/s Ethernet port sends the 64-byte Ethernet packets at a delay shorter than 20 μs. |
| BER in full load | BER of a port when the port transmits data in full load < 10 e-7 |
| System reliability specifications |
System: redundant configuration. System availability for the typical configuration: > 99.999%. Mean time between failures (MTBF): about 45 years. (for reference). |
| Operating environment |
Operating temperature: -40°C ~ +65°C Operating humidity: 5% ~ 95% RH Atmospheric pressure: 61 ~ 106 kPa Altitude: ≤ 4000 m |
| Max. number of ADSL2+ / VDSL2 / POTS ports | 128 |
| Max. number of EFM SHDSL /ISDN BRA / ISDN PRA ports | 64 |
| Max. number of TDM SHDSL / GPON ports | 32 |
| Max. number of 10G GPON ports | 8 |
| Max. number of P2P FE / GE ports | 96 |
| Parameter | Specification |
|---|---|
| Powering Options | DC: -38.4VDC to -72VDC; AC: 100V to 240V |
| Dimensions (Height x Width x Depth) | 3.47in x 17.4in x 9.63in |
| Operating Temperature | -40º F to +149º F |
| Storage Temperature | -40º F to +158º F |
| SFP | Class C C+,C++ |
| Cooling | Two multispeed fans, providing left to right forced air flow |
| Operating Humidity | 5% to 85%, non-condensing, Altitude: 197 ft (60 m) below sea level to 13,123 ft (4,000 m) above sea level |
The system features a switching capacity of 128 Gbit/s in active/standby mode and 256 Gbit/s in load-sharing mode using MCUD/MCUD 1. The switching/forwarding delay for 100 Mbit/s Ethernet ports sending 64-byte packets is shorter than 20 μs.
The system operates reliably in temperatures ranging from -40°C to +65°C (-40°F to +149°F) and storage temperatures from -40°F to +158°F. It supports operating humidity levels between 5% and 95% RH, atmospheric pressures of 61 to 106 kPa, and altitudes up to 4000 m (13,123 ft).
The system supports up to 32 GPON ports (configured with either 8 or 16 ports per card) and a maximum of 8 10G GPON (XG-PON1) ports (configured with 4 ports per card).
The GPON interfaces are compliant with G.984 Series standards, offering 2.5/1.2 Gbps line rates. They support B+ or C+ SFP optical modules with up to 40km differential distance, up to a 1:128 split ratio, Optical Power Monitoring, and Real-Time Rogue ONT detection/isolation.
The system supports both DC power input (-38.4VDC to -72VDC) and AC power input (100V to 240V). Cooling is managed by two multispeed fans that provide left-to-right forced air flow.
The Combo card integrates 48 VDSL2 and POTS ports supporting up to 17a profiles, two-pair bonding, G.INP (G.998.4) re-transmission, built-in SELT/DELT/MELT diagnostics, POTS line Loop-Start, balanced ringing (-15VDC offset on Ring), and multiple audio CODECs (G.711, G.729, G.723, G.726).
