| Parameter | Details |
|---|---|
| Model | HG8120C |
| PON | GPON |
| Port | 1GE+1FE+1TEL |
| Color | White |
| Size/weight | 162*141*36mm / 0.3KG |
| Wi-Fi | None |
| Connector type | SC/UPC |
| Power adapter | EU, US and UK |
| Power consumption | 5W |
| Humidity | 5%-95% (No condensation) |
| Working temperature | -10°C to +45°C |
| Firmware | English |
| PPPOE | Support |
| Pilot Lamp | Status | Description |
|---|---|---|
| PWR | On | The device is powered up. |
| Off | The device is powered down. | |
| PON | On | The device has registered to the PON system. |
| Blink | The device is registering to the PON system. | |
| Off | The device registration is incorrect. | |
| LOS | Blink | The device does not receive optical signals. |
| Off | The device has received optical signal. | |
| FXS | On | Phone has registered to the SIP Server. |
| Blink | Phone has registered and data transmission (ACT) is active. | |
| Off | Phone registration is incorrect. | |
| LAN1~LAN2 | On | Port (LANx) is connected properly (LINK). |
| Blink | Port (LANx) is sending or/and receiving data (ACT). |
Plug and Play (PnP): Just click NMS to deploy Internet and IPTV services; no on-site configuration is required.
Remote Diagnosis: Realize remote fault location through accurately located feeders and lead-in cables, identifying both software and hardware problems.
High-Speed Forwarding: GE wire-speed forwarding for optimal network transmission rates.
EPON/GPON Compatibility: Support EPON and GPON Mode with automatic switching.
Auto-Discovery & Upgrades: Supports ONU auto-discovery, link detection, and remote software upgrades.
Flexible WAN Connections: WAN connections support both Route and Bridge modes.
Route Mode Protocols: Route mode supports PPPOE, DHCP, and static IP configuration.
Traffic Control: Supports Quality of Service (QoS) and Dynamic Bandwidth Allocation (DBA).
VLAN & Isolation: Support port isolation and port VLAN configuration.
Security & Multicast: Support firewall functions and IGMP snooping multicast features.
IP Allocation: Support LAN IP and DHCP Server configuration.
Loop Detection: Support Port Forwarding and Loop-Detect features.
Remote Management: Support TR069 remote configuration and maintenance protocols.
VoIP Voice Support: Support POTS interface for VoIP service integration.
System Stability: Specialized design for system breakdown prevention to maintain a stable, running environment.
